Genuine Sauer Danfoss 90M075 Fixed Displacement Hydraulic Piston Motors
| PRODUCT DESCRIPTIONS
Danfoss Series 90 75 cc Axial Piston Motors | Fixed Displacement Hydraulic Piston Motors
The genuine Sauer Danfoss 90M075 motors feature a parallel axial piston/slipper design and a fixed swashplate. They can intake/discharge fluid through either port; they are bidirectional. They also include an optional
loop flushing feature that provides additional cooling and cleaning of fluid in the working loop.
• Series 90 – advanced technology today
• Seven sizes of variable displacement pumps
• Four sizes of fixed displacement motors
• SAE and cartridge mount configurations
• Efficient axial piston design
• Proven reliability and performance
• Compact, lightweight
• Worldwide sales and service
| PRODUCT SPECIFICATIONS
Parameter | Value |
Displacement | 75 cm³ [4.57 in³] |
Max. working pressure | 450 bar [6,525 psi] |
Continuous Speed at Max. Displacement | 3,600 rpm |
Theoretical torque | 1.19 Nm/bar [730 lbf -in/1,000 psi] |
Weight --- SAE | 26 kg [57 lb] |
Weight --- Cartridge | 33 kg [72 lb] |
| MODEL OPTIONS
90M075 Series |
517600 90-M-075-NC-0-N-8-N-0-C7-W-00-NNN-00-00-F3 90M075NC0N8N0C7W00NNN0000F3 |
518302 90-M-075-NC-0-N-8-N-0-C7-W-00-EFA-00-00-F3 90M075NC0N8N0C7W00EFA0000F3 |
675637 90-M-075-NC-0-N-7-N-0-C7-W-00-NNN-00-00-F0 90M075NC0N7N0C7W00NNN0000F0 |
700423 90-M-075-NC-0-N-7-N-0-C6-W-00-EFA-00-00-F3 90M075NC0N7N0C6W00EFA0000F3 |
704619 90-M-075-NC-0-N-7-N-0-D4-W-00-NNN-00-00-A3 90M075NC0N7N0D4W00NNN0000A3 |
768713 90-M-075-NC-0-N-7-N-0-C7-W-00-NNN-00-00-F3 90M075NC0N7N0C7W00NNN0000F3 |
80004627 90-M-075-NC-0-N-8-N-0-C7-W-00-EFA-00-00-F0 90M075NC0N8N0C7W00EFA0000F0 |
83001523 90-M-075-NC-0-N-8-N-0-C6-W-00-NNN-00-00-N4 90M075NC0N8N0C6W00NNN0000N4 |
| PRODUCT FEATURES
• Four sizes of fixed displacement motors
• SAE and cartridge mount configurations
• Efficient axial piston design
• Proven reliability and performance
• Compact, lightweight
| PRODUCT APPLICATIONS
• Agriculture (e.g., harvesters, combines, windrowers)
• Construction (e.g., pavers, rollers, trenchers, specialty equipment)
• Material handling
• Forestry
• Turf care
• Mining equipment
• Specialty equipment
