Original Sauer Danfoss H1B160 Bent Axis Variable Hydraulic Piston Motors

Original Sauer Danfoss H1B160 Bent Axis Variable Hydraulic Piston Motors

| PRODUCT DESCRIPTIONS

Danfoss H1B160 Piston Motors | Variable Displacement Bent Axis Design

The Danfoss H1B160 is a high-torque, bent-axis hydraulic motor designed for demanding mobile and industrial applications. Its design features include:

• Mechanical Configuration: bent-axis design with 25°-40° adjustable angle for variable displacement

• Hardened steel components: HRC 60+ hardened pistons and precision-ground cylinder block

• Hydraulic Circuit:advanced porting geometry for optimized flow (pressure losses <0.3 bar at nominal flow)

• Control System(HEHENBTBCNLN control block features):hydraulic displacement control, mechanical servo piston with position feedback and ptional electro-hydraulic proportional control

• Sealing System: triple-lip shaft seal (standard NBR or optional FKM) and pressure-balanced piston seals for high-speed operation

| PRODUCT SPECIFICATIONS

| MODEL OPTIONS

This motor represents Danfoss' advanced hydraulic technology, combining robust construction with precise control capabilities for heavy-duty applications. The model's extended code indicates specific configuration options for shaft type, ports, and control features.

| PRODUCT APPLICATIONS

• Construction: Track drives for 20-50 ton excavators

• Agriculture: Combine header drives (30-100 L/min flow range)

• Mining: Continuous miner cutting head drives

• Wind energy: Pitch control systems (3-7 MW turbines)

• Marine: Deck crane slewing drives (200-500 kNm applications)

• Material handling: Palletizer rotary actuators

• Military: Armored vehicle propulsion

• Oil & gas: Mud pump drives

• Rail: Diesel-hydraulic transmission systems

Pls contact us directly by：

Tel./WhatsApp/WeChat: +86 138 6780 9523

Email: wfu@phpfluid.com

we can discuss the details, thanks.
